CIRS 801-P男性骨盘模体

CIRS 801-P男性骨盘模体，CIRS 801-P模体

CIRS 801-P男性骨盘模体是我们最现实的，组织当量幻像可用。模体被设计用于诊断放射学和放射治疗成像剂量学教学和示范应用。模体的所有解剖尺寸都基于可见人类项目（VHP）数据集，可作为人体解剖学研究的参考，可通过国家医学图书馆获取。

CIRS 801-P男性骨盘模体将这一解剖细节与我们先进的组织模拟技术相结合。CIRS 801-P男性骨盘模体由专有的环氧材料制成，模拟人类组织的密度和辐射衰减特性，从50keV到25MeV，范围在1％以内。它包含解剖学上精确的骨，软骨，脊髓，椎间盘，肌肉，肠，膀胱，前列腺，直肠和间质脂肪。



CIRS 801-P男性骨盘模体技术规格
尺寸： 35.6厘米×30.5厘米×25.4厘米（14“×12”×10“）
幻像重量： 24.9千克（55磅）
材料：环氧树脂
密度： 0.96g / cc

CIRS 801-P男性骨盘模体包括的材料
男性骨盆模体
手提箱
用户指南
保修信息
4年保修







CIRS 801-P男性骨盘模体，CIRS 801-P模体英文介绍：


The CIRS Model 801-P phantom is our most realistic, tissue equivalent phantom available.  The phantom was designed for use in diagnostic radiology and radiation therapy for imaging dosimetry teaching and demonstration applications.  All anatomical dimensions of the phantom are based on The Visible Human Project (VHP) data sets that serve as a reference for the study of human anatomy and are available through the National Library of Medicine.

CIRS has combined this anatomical detail with our advanced tissue mimicking technology.  The phantom is made from proprietary epoxy materials that mimic the density and radiation attenuation properties of human tissue within 1% from 50 keV to 25 MeV.  It contains anatomically precise bone, cartilage, spinal cord, vertebral disks, muscle, intestines, bladder, prostate, rectum and interstitial fat.

Features:
based on the Visible Human Project data set

Superior tissue simulation and lifelike imaging properties

Accommodates wide variety of detectors
