日本kyoto PH-47牙科造影头模详细介绍：
日本kyoto PH-47牙科造影头模专为具有内部结构的最先进的合成牙齿的口外（全景）造影术而设计。可移动的下巴和舌头允许各种应用程序的培训和研究。
日本kyoto PH-47牙科造影头模特征：
每颗牙齿分别建模并具有三层结构的牙釉质，牙本质和牙髓腔。
每个硬组织（牙釉质，牙本质，皮质骨和松质骨）具有特定的HU值和X射线吸收率。
大白鲨和舌头是可拆卸的，以允许进入口腔，咽腔和上颌窦。可以在这些空腔中设置检查器或模拟损伤或残留物。
颈动脉被制备成流明以适应模拟钙化。
培训技能和QA应用程序
口外（全景）放射照相
口内X线摄影*
牙科CT
头影和其他头部X光片
*闭口位
日本kyoto PH-47牙科造影头模解剖
合成颅骨有鼻腔，上颌窦，舌骨，下颌牙槽和上颌牙槽; 颈椎和舌骨，牙釉质，牙本质和牙髓腔。
舌，口腔，咽腔和颈动脉
规格
日本kyoto PH-47牙科造影头模套装包括：
1个主要头部单位
1上颚（牙槽骨）
1下颌（牙槽骨）
1个舌头
1个固定座（含螺丝）
1个三脚架
1个铝制储物箱
Dental Radiography Head Phantom - PH-47 - Kyoto Kagaku
Dental Radiography Head Phantom is designed for extra-oral (panoramic) radiography featuring state-of-the-art synthetic teeth with internal structures. Removable jaws and tongue allow a variety of application for training and research.
Features:
Each tooth is individually modeled and has a three-layer structure of enamel, dentin and pulp cavity.
Each hard tissue (enamel, dentin, cortical bone and cancellous bone) has a particular HU number and X-ray absorption rate.
Jaws and tongue are detachable to allow access to the oral cavity,
pharyngeal cavity and maxillary sinus. Censors or simulated lesions or
residue can be set in these cavities.
Carotid arteries are prepared as lumens to accommodate simulated calcifications.
Training Skills and QA Applications
Extra-oral (Panoramic) radiography
Intraoral radiography*
Dental CT
Cephalography and other head radiography
*with closed mouth position
Anatomies
Synthetic skull with nasal cavity, maxillary sinus, hyoid bone,
mandible alveolar, and maxillary alveolar; cervical vertebrae and hyoid
bone, teeth with enamel, dentin and pulp cavity.
Tongue, oral cavity, pharyngeal cavity and carotid arteries
Specifications
Set Includes:
1 main head unit
1 upper jaw (alveolar bone)
1 lower jaw (alveolar bone)
1 tongue
1 fixation base (including screws)
1 tripod
1 aluminum storage case
